Unicorn Video Management Server VMS from Uniview

Univiews Unicorn Video Management Server VMS is for managing large surveillance applications. This VMS server can handle up to 2000 IP Camera Connections and up to 1000 devices. If you have done some large surveillance camera projects, you know that each presents unique challenges. Therefore the Unicorn VMS server can be custom designed for your application. Optional Hard Drive Disk enclosures are available, as well as additional Decoding Cards. Other features include RAID, Hot Swap HDD, and E-Map Function. Perfect for security applications, the Unicorn VMS provides reliable video management, seamless ONVIF integration, and scalability to meet your needs.

Unicorn VMS Server Overview:

• Third party IP Cameras Supported with ONVIF
• Support for Mobile Clients (iOS and Anroid) access
• Up to 1000 Devices / Up to 2000 Channels
• Unified Management of NVR, IP Cameras, Decoder, Network Keyboard and Cloud Devices
• 16 SATA HDDs, Up to 14TB each HDD
• 16 X 1080P Decoding Outputs in 3 Screens
• Support for Live View, Playback, Sequence, Video Wall, E-Map, Two Way Alarm, Alarm Plan
• Support of Network Fault Tolerance, Multi IP Configuration and Load balancing



Unicorn VMS Server Features:

• Stability: Linux OS, dual-BIOS, redundant power, two-server hot standby
• Compatibility: Third-party IP Cameras supported with standard ONVIF
• Access: Browser/Server, Client/Server and mobile clients (both iOS and Android)
• Connection: 1000 device connections, up to 2000 channels of high-definition network videos
• Management: Unified management of NVR, IPC, decoder, network keyboard, cloud devices, alarm control panel and door access control, support devices’ configuration import/export
• Storage: Max 16 hard disks and 2 disk enclosures; expandable up to 48 disks with 672TB storage, recording backup, IPSAN storage
• Decoding: Max 16×1080P decoding outputs in three screens, expandable up to 112×1080P in 15 screens with 2 decoding cards inserted
• Service: Live view, playback, sequence, video wall, E-map, two-way audio, and alarm plan
• Reliability: Support of HTTPS, 802.1x authentication, ARP protection, Telnet enabling/disabling, network fault tolerance, multi-IP configuration, load balancing, secure password and IP address filtering

    RAID Support The Unicorn provides RAID Support for RAID0, RAID1, RAID5, RAID6, RAID10, RAID50, RAID60       ONVIF Support Third Party Cameras are supported through ONVIF Protocol. UNV is a full ONVIF Member.       Hot Swap HDD A Hot Swap Hard Drive Function is supported.

Simple Monitoring Diagram for Unicorn Video Management Server:



Unicorn E-Map Function for Camera Location Identification:



VMS and Mobile Client support Unicorn Video Management Server VMS:



EZStation Video Management Software

Unified management for Uniview’s IP cameras, NVRs, hybrid NVRs, network keyboards, decoding devices and more. Device Management and diverse features.

EZView Mobile App

View from anywhere via Mobile Device with our Free EZView Mobile App for Android and iOS. Uniview NVR’s support Mobile Client, Push Alerts, Email Notifications and P2P

---

Expansion for Unicorn VMS:

• 1 X SATA
• 2 X MiniSAS
• 2 X Decoding Card

Optional HDD Enclosures:

• DEU1008 (8) X SATA
• DEU1016 (16) X SATA



---



Take IP to the Next Level with Uniview

NVR’s from Uniview are packed with advanced features and are extremely user friendly. As a result, it has become the choice for many of our Dealers and Integrators due to ease of use and low failure rates. Uniview has completed major projects around the globe and is the perfect choice for a broad range of surveillance applications.
